R183-Z94-AAD2 Gigabyte Dual EPYC 9005 1U 6NR183Z94DR000ACD2 Server Barebone

Product version:

Rev-3.x

Product line:

Gigabyte R Series

See all Rackmount Servers 1U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SE8B3251-863931

Manufacturer Number:

6NR183Z94DR000ACD2

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NR183Z94DR000ACD2?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R183-Z94-AAD2 Gigabyte

High-Density 1U Dual-Socket Rack Server Barebone with Gen5 I/O and 12-Bay Storage using the R183-Z94-AAD2 Gigabyte

The R183-Z94-AAD2 Gigabyte barebone, SKU 6NR183Z94DR000ACD2, is a 1U dual-socket platform built around AMD EPYC 9005/9004 (Turin/Genoa) on SP5, enabling high core density with up to 400W TDP per CPU for compute-heavy clusters. Its DDR5 ECC RDIMM design with 24 DIMM slots and 12-channel memory per CPU supports balanced bandwidth and capacity scaling to 6TB, aligning with consolidation targets for virtualized and scale-out environments.

For I/O-centric designs, the R183-Z94-AAD2 Gigabyte delivers PCIe 5.0 expansion including 2 full-height, half-length x16 slots suitable for accelerators or high-throughput adapters, plus 2 OCP NIC 3.0 PCIe 5.0 x16 bays with NCSI support for modern fabric connectivity. Storage is optimized for tiered architectures: 12 front hot-swap 2.5in bays with a flexible mix of NVMe Gen5 x4 and SAS-4/SATA, complemented by 3 internal M.2 devices for OS or hypervisor boot separation from data tiers.

Why Choose the R183-Z94-AAD2 Gigabyte?

The R183-Z94-AAD2 Gigabyte is engineered for enterprises that need predictable scaling in a 1U footprint, combining dual-socket CPU density, Gen5 I/O headroom, and hot-swap serviceability. This architecture supports repeatable node builds for clusters, simplifies lifecycle expansion with OCP NIC 3.0, and maintains operational resilience through redundant, hot-swap power and out-of-band management.

Gigabyte applies data centre-focused engineering with validated platforms, consistent firmware management via AMI UEFI, and ASPEED AST2600 BMC features such as IPMI and HTML5 KVM to align with remote operations and standardized rack deployment practices.

Key Applications:

Virtualization and private/hybrid cloud compute
Database and scale-out compute nodes
Software-defined storage with mixed NVMe + SAS/SATA tiers
Edge aggregation and infrastructure services

At Happyware - Server Hardware you benefit from non-binding offers tailored to your R183-Z94-AAD2 Gigabyte configuration and an extended warranty of up to 6 years to protect long-term platform standardization in production environments.

Technical details of R183-Z94-AAD2 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

SP5 (LGA 6096)

CPU Family:

EPYC

Supported CPU Manufacturer:

AMD

Supported CPU Type:

EPYC 9004 EPYC 9005

Supported CPU Generation:

4th 5th

Supported CPU Codename:

Genoa Turin

Nodes:

RAM Type:

RDIMM

RAM Max. Total:

6TB

RAM Slots Total:

ECC Support:

ECC

Bays:

4x 2.5" HotSwap NVMe, SATA, SAS 8x 2.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

2x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

2x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

2x RJ45 1 Gbps Intel I350-AM2

Onboard Network LAN Speed:

1 Gbps

Front I/O Ports:

System status LED Storage Activity LED LAN Activity LED Power button with LED System Reset button USB UID button with LED

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

1600W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Platinum

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

400W

Applications:

Networking Hybrid/Private Cloud Server Enterprise

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Chassis Intrusion:

OS:

Windows Server

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for R183-Z94-AAD2 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
