R183-S93-AAC2 Gigabyte
High-Density 1U Dual-Socket Rack Server Barebone engineered for DDR5 and PCIe 5.0 expansion with the R183-S93-AAC2 Gigabyte
The R183-S93-AAC2 Gigabyte 1U barebone targets enterprise consolidation where core density, memory bandwidth, and predictable I/O are critical. Built on the Intel C741 platform with LGA4677, it supports dual Intel Xeon Scalable 5th/4th Gen processors up to 350W per CPU, aligning with virtualization hosts and general-purpose private cloud nodes that require high per-rack throughput without sacrificing serviceability.
For memory-centric workloads, the R183-S93-AAC2 Gigabyte provides 32 DDR5 RDIMM ECC DIMM slots with 8-channel memory per CPU, enabling up to 8TB capacity for high-VM density and in-memory services. PCIe 5.0 connectivity is delivered through 2 FHHL x16 slots and 2 OCP NIC 3.0 PCIe 5.0 x16 interfaces to scale network fabrics and offload adapters. Storage is optimized for operational continuity with 4 hot-swap SAS/SATA bays; SATA RAID is supported onboard, while SAS can be enabled via an add-in HBA, keeping the storage path adaptable to policy-driven designs.
Why Choose the R183-S93-AAC2 Gigabyte?
The R183-S93-AAC2 Gigabyte balances compute density with expansion headroom, allowing architects to standardize a 1U building block across virtualization, hybrid cloud, and infrastructure roles. Redundant hot-swap power, out-of-band management, and modular I/O scaling via PCIe 5.0 and OCP NIC 3.0 support repeatable deployment patterns and efficient lifecycle operations in multi-node racks.
Gigabyte engineers this platform for modern data centre integration, focusing on validated server thermals, resilient power delivery, and management parity through ASPEED AST2600 BMC with IPMI and HTML5 KVM. The design aligns with enterprise governance needs, including optional TPM 2.0 enablement via SPI header and clear guidance on single-CPU configuration trade-offs.
Key Applications:
- VMware/Hyper-V/Citrix host consolidation
- Hybrid and private cloud compute nodes
- Edge services and control-plane infrastructure
- Security and network services appliances
At Happyware - Server Hardware you benefit from 24/7 Customer Service to support configuration and rollout planning for the R183-S93-AAC2 Gigabyte, and you can secure additional investment protection by extending the warranty up to 6 years.
Technical details of R183-S93-AAC2 Gigabyte
How long is the Warranty and how you can get technical support for R183-S93-AAC2 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
