R183-S90-AAV2 Gigabyte
High-Density 1U Dual-Socket Rack Server Platform for PCIe 5.0 I/O and DDR5 Capacity with R183-S90-AAV2 Gigabyte
R183-S90-AAV2 Gigabyte is a 1U rack server barebone built on the Intel C741 platform to host 4th/5th Gen Intel Xeon Scalable processors (LGA4677) for enterprise virtualisation, network infrastructure services, and general-purpose compute. The dual-socket design supports high-core-count configurations with up to 350W TDP per CPU, enabling consistent performance under mixed VM, container, and appliance-style workloads.
For memory-intensive consolidation, R183-S90-AAV2 Gigabyte implements DDR5 ECC RDIMM across 32 DIMM slots with 8-channel memory per CPU, scaling up to 8TB to reduce contention and improve QoS for multi-tenant platforms. PCIe 5.0 expansion is delivered via 2 x x16 FHHL riser slots for accelerators, high-speed storage controllers, or high-throughput NICs. Storage is architected around 4 front hot-swap bays for 2.5"/3.5" SATA/SAS, with SAS enabled through an add-in HBA/RAID, while onboard Intel SATA RAID and VROC key header support provide flexible boot and mirror options.
Why Choose the R183-S90-AAV2 Gigabyte?
R183-S90-AAV2 Gigabyte delivers a strong density-to-performance ratio in 1U by combining dual-socket compute, high DDR5 capacity, and PCIe 5.0 lanes for scalable I/O and east-west networking. The platform is designed for predictable operations with remote lifecycle control, redundant power, and modular network expansion suited to growth-oriented clusters.
Gigabyte engineers the R Series with an emphasis on serviceability and data centre alignment, pairing standards-based components with robust management. R183-S90-AAV2 Gigabyte includes an ASPEED AST2600 BMC with IPMI and remote KVM, dedicated management LAN, and NCSI-capable OCP NIC 3.0 support for controlled deployments, plus optional TPM 2.0 for security policy integration.
Key Applications:
- Enterprise virtualisation and private cloud
- Hybrid cloud edge nodes
- Network services and infrastructure appliances
- Backup and general-purpose compute
- High-throughput storage gateway
At Happyware - Server Hardware you benefit from non-binding offers tailored to your R183-S90-AAV2 Gigabyte rollout and an extended warranty up to 6 years to secure long-term platform availability for enterprise operations.
Technical details of R183-S90-AAV2 Gigabyte
How long is the Warranty and how you can get technical support for R183-S90-AAV2 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
