R183-S90-AAD1 Gigabyte
High-Density 1U Dual-Socket Rack Server Barebone for Intel C741 Platforms with the R183-S90-AAD1 Gigabyte
The R183-S90-AAD1 Gigabyte (SKU: 6NR183S90DR000ABD1) is a 1U rack server barebone engineered for dual Intel Xeon Scalable 5th/4th Gen processors on the LGA4677 Intel C741 platform, targeting compute-dense clusters where power, thermals, and serviceability must be tightly controlled. With support for up to 350W CPUs per socket, it aligns well with consolidation-driven virtualisation nodes and balanced database tiers.
Its DDR5 ECC RDIMM design provides 32 DIMM slots with 8-channel memory per CPU, enabling high bandwidth and capacity scaling up to 8TB for memory-intensive VMware/Hyper-V host profiles and in-memory analytics. PCIe 5.0 expansion delivers two x16 FHHL slots plus dual OCP NIC 3.0 SFF (PCIe 5.0 x16) interfaces, allowing flexible NIC selection while preserving lane efficiency for accelerators and high-speed I/O. Storage is architected for mixed media: 4 hot-swap 2.5"/3.5" bays supporting NVMe Gen4 x4 or SATA, with SAS 12Gb/s available through an optional HBA/RAID card, complemented by Intel SATA RAID and VROC readiness for controlled NVMe RAID strategies.
Why Choose the R183-S90-AAD1 Gigabyte?
The R183-S90-AAD1 Gigabyte prioritises density-to-performance in 1U without compromising operational resilience, pairing redundant 1600W 80 PLUS Platinum hot-swap PSUs with an enterprise management stack for repeatable scale-out deployments. The platform’s balanced compute, memory channels, and I/O topology supports predictable growth from small clusters to larger private cloud fabrics.
Gigabyte designs the R series around data centre lifecycle requirements, combining standards-aligned component selection with service-friendly layouts, validated management via ASPEED AST2600 BMC, and compatibility focus for modern rack, power, and network architectures.
Key Applications:
- VMware vSphere and Hyper-V compute clusters
- Private cloud infrastructure nodes
- Edge networking services and appliances
- General-purpose virtualised workloads
- Database and mixed storage tiers
At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your R183-S90-AAD1 Gigabyte configuration and an extended warranty up to 6 years to protect long-term platform standardisation.
Technical details of R183-S90-AAD1 Gigabyte
How long is the Warranty and how you can get technical support for R183-S90-AAD1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
