R164-SG6-AAJ1 Gigabyte

High-Density 1U PCIe Gen5 GPU Rack Server for AI and NVMe-First I/O with the R164-SG6-AAJ1 Gigabyte

The R164-SG6-AAJ1 Gigabyte is a 1U single-node GPU rack server engineered around an Intel Xeon 6 (LGA4710 E2) SoC platform, supporting Granite Rapids or Sierra Forest to align core density and per-core throughput with modern AI inference and edge-to-core service tiers. With 16 DDR5 ECC DIMM slots for RDIMM or MRDIMM configurations up to 4TB, the memory subsystem is designed to sustain large model working sets and virtualization consolidation while maintaining enterprise-grade error protection.

For accelerated compute, the R164-SG6-AAJ1 Gigabyte exposes PCIe 5.0 expansion with 2x x16 FHFL GPU-capable slots plus an additional x16 FHHalfL slot, enabling balanced GPU and I/O provisioning in a constrained rack footprint. Storage is NVMe-centric: 16 front hot-swap E3.S bays support a Gen5-class architecture for high-IOPS data paths, while dual M.2 PCIe Gen5 boot options isolate OS and hypervisor media from workload datasets. Management is handled by an ASPEED AST2600 BMC with IPMI and HTML5 KVM, supporting remote lifecycle control at scale.

Why Choose the R164-SG6-AAJ1 Gigabyte?

The R164-SG6-AAJ1 Gigabyte delivers a practical density-to-performance ratio for GPU-accelerated inference, visual compute, and NVMe-heavy service nodes where rack space, power envelopes, and operational consistency drive platform selection. Its PCIe Gen5 topology and hot-swap NVMe design support scalable expansion and predictable serviceability, while redundant 80 PLUS Titanium power supplies help maintain uptime in production clusters.

Gigabyte applies a systems engineering approach focused on validated platform interoperability, service-friendly mechanical design, and alignment with data centre operational standards, including remote management, redundant power, and modular expansion for lifecycle stability.

Key Applications:

AI inference and model serving
GPU-accelerated VDI and visual computing
High-IOPS NVMe data services
Edge-to-core hybrid private cloud nodes

At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration requirements for the R164-SG6-AAJ1 Gigabyte and an extended warranty of up to 6 years to protect long-term infrastructure investments.

Technical details of R164-SG6-AAJ1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

E2 (LGA 4710)

CPU Family:

Xeon 6

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon 6700 w/ P-cores Xeon 6700 w/ E-cores Xeon 6500 w/ P-cores Xeon 6 SoC

Supported CPU Generation:

6th

Supported CPU Codename:

Sierra Forest Granite Rapids

Nodes:

RAM Type:

RDIMM MRDIMM

RAM Max. Total:

4TB

RAM Slots Total:

Memory Slots:

ECC:

ECC

Bays:

16x E3.S HotSwap NVMe

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

1x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

1x PCIe 5.0 x16 Full-Height Half-Length 1x PCIe 5.0 x16 Full-Height Full-Length (Standard)

Front I/O Ports:

USB Type-A LED Indicators

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

2000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Power Supply Cooler:

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

350W

Applications:

AI / Deep Learning AI Inference Networking Visual Computing Hybrid/Private Cloud Server

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Pre-installed Components:

None

Certificates:

80 Plus Titanium

Chassis Intrusion:

How long is the Warranty and how you can get technical support for R164-SG6-AAJ1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
