R164-SG2-AAV1 Gigabyte Single Xeon 6 SoC 1U 6NR164SG2DR000AAV1 Server Barebone

Product line:

Gigabyte R Series

See all Rackmount Servers 1U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SH1B1227-967279

Manufacturer Number:

6NR164SG2DR000AAV1

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

R164-SG2-AAV1 Gigabyte

High-Density 1U GPU-Optimized Rack Server Barebone with PCIe Gen5 Expansion using the R164-SG2-AAV1 Gigabyte

The R164-SG2-AAV1 Gigabyte is a 1U single-socket platform engineered for GPU-accelerated inference, VDI, and edge-adjacent deployments where PCIe bandwidth and thermal design are the gating factors. Built around Intel Xeon 6 (Granite Rapids or Sierra Forest) on LGA4710, it supports high core-count configurations up to 350W TDP to balance CPU throughput with accelerator feeding and I/O concurrency.

Memory is provisioned through 16 DDR5 ECC RDIMM/MRDIMM slots, scaling to 4TB to sustain larger model caches, dense VDI sessions, and NFV state tables with predictable error handling. The R164-SG2-AAV1 Gigabyte exposes PCIe Gen5 lanes for accelerator and storage concurrency, offering 2 PCIe 5.0 x16 FHFL slots for full-length cards plus an additional PCIe 5.0 x16 FHHL slot for expansion. Storage architecture is optimized for mixed performance tiers with 12 x 2.5in hot-swap bays, including 4 bays supporting NVMe/SATA/SAS and 8 bays for SATA/SAS, complemented by dual M.2 NVMe PCIe Gen5 boot devices to keep the front bays available for workload data.

Why Choose the R164-SG2-AAV1 Gigabyte?

The R164-SG2-AAV1 Gigabyte delivers a high density-to-performance profile for enterprises consolidating GPU inference or visual computing into minimal rack units without sacrificing serviceability. It pairs Xeon 6 scalability with Gen5 expansion and redundant power to support repeatable deployments across edge clusters or private cloud pods while maintaining predictable remote operations through BMC management.

Gigabyte applies data centre-aligned engineering focused on validated thermals, component interoperability, and lifecycle stability, enabling consistent rollouts and disciplined change control in mixed-workload environments.

Key Applications:

AI inference and edge GPU acceleration
VDI and visual computing
Hybrid/private cloud compute nodes
Network functions virtualization (NFV)

At Happyware - Server Hardware you benefit from non-binding offers tailored to your R164-SG2-AAV1 Gigabyte configuration and extended warranty options up to 6 years to secure long-term platform continuity for production deployments.

Technical details of R164-SG2-AAV1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

E2 (LGA 4710)

CPU Family:

Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon 6 SoC Xeon 6700 Xeon 6500

Supported CPU Generation:

6th

Supported CPU Codename:

Sierra Forest Granite Rapids

Nodes:

RAM Type:

RDIMM MRDIMM

RAM Max. Total:

4TB

RAM Slots Total:

ECC Support:

ECC

Bays:

4x 2.5" HotSwap NVMe, SATA, SAS 8x 2.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

1x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

1x PCIe 5.0 x16 Full-Height Half-Length 1x PCIe 5.0 x16 Full-Height Full-Length (Standard)

Front I/O Ports:

System status LED Storage Activity LED Power button with LED System Reset button USB UID button with LED

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

1600W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

350W

Applications:

AI/Deep Learning AI Inference Networking Visual Computing Hybrid/Private Cloud Server

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Supported GPU Type:

PCIe

Certificates:

80 Plus Titanium

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for R164-SG2-AAV1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
