R123-X00-AA01 Gigabyte
High-Density 1U Single-Socket Rack Server Platform with PCIe 5.0 Expansion using the R123-X00-AA01 Gigabyte
R123-X00-AA01 Gigabyte is a 1U, 1-node barebone engineered around the Intel LGA1700 ecosystem, supporting Intel Xeon E-2400 or Xeon 6300 series processors up to 95W on the Intel C262 chipset for efficient, predictable compute in constrained racks. The platform is designed for virtualization hosts and general-purpose Windows/Linux infrastructure where per-node cost, remote manageability, and deterministic performance matter more than multi-socket scale.
With 4 DDR5 ECC UDIMM slots, R123-X00-AA01 Gigabyte enables a balanced memory footprint for VM consolidation and edge services while maintaining ECC integrity. Expansion is optimized for modern I/O: a PCIe 5.0 x16 slot supports high-bandwidth NICs or accelerators, complemented by 2 PCIe 4.0 x4 slots for additional networking or storage controllers. Storage architecture combines 4 front hot-swap SATA 6Gb/s bays for serviceable capacity and an internal M.2 PCIe 4.0 x4 NVMe slot for fast boot or cache, aligning the chassis with hybrid/private cloud nodes and compact branch deployments.
Why Choose the R123-X00-AA01 Gigabyte?
R123-X00-AA01 Gigabyte delivers an enterprise-ready density-to-performance profile by pairing a single-socket Xeon platform with PCIe 5.0 expansion and serviceable 1U storage, enabling scale-out designs that grow linearly per rack unit. Integrated ASPEED AST2600 BMC management with IPMI and HTML5 KVM supports lights-out operations, while Intel SATA RAID and optional add-in RAID provide flexible data-path control for standardized deployments.
Gigabyte focuses on pragmatic server engineering: validated thermals in compact chassis, conservative power design with a 400W 80 PLUS Gold hot-swap PSU, and management features aligned to contemporary data center operational standards. R123-X00-AA01 Gigabyte also supports security integration via a TPM header for environments requiring measured boot policies.
Key Applications:
- Virtualization host for SMB and edge clusters
- Hybrid/private cloud scale-out nodes
- Windows/Linux infrastructure services
- Branch office and remote site compute
- Lightweight storage and backup targets
At Happyware - Server Hardware you benefit from non-binding offers tailored to your deployment plan for the R123-X00-AA01 Gigabyte, enabling fast procurement alignment across projects, and you can extend the warranty up to 6 years to secure long-term operation in distributed or always-on environments.
Technical details of R123-X00-AA01 Gigabyte
How long is the Warranty and how you can get technical support for R123-X00-AA01 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
