MC12-LE0 Gigabyte microATX Single AM4 4 DIMM Slots Workstation Mainboard

*Picture may not be exactly the same as the product

Product version:

Rev-1.x

See all ECC RAM Supported Motherboard

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

In stock

Happyware Article Number:

SH3M2718-196008

Manufacturer Number:

MC12-LE0

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

MC12-LE0 Gigabyte

MicroATX Embedded/Workstation Server Motherboard architecture with remote management using the MC12-LE0 Gigabyte

The MC12-LE0 Gigabyte is a microATX server motherboard designed for AMD AM4 platforms on the B550 chipset, aligning Ryzen-class CPUs up to 105W with an embedded-ready feature set for edge compute and compact server nodes. Its integrated IPMI/BMC with dedicated management LAN enables out-of-band provisioning, monitoring, and recovery workflows that reduce hands-on intervention in distributed deployments.

For memory architecture, MC12-LE0 Gigabyte provides dual-channel DDR4 with 4 DIMM slots up to 128GB, supporting ECC and non-ECC to balance integrity requirements with cost targets. PCIe 4.0 expansion delivers a primary x16 slot for accelerators, high-throughput NICs, or capture cards, complemented by an additional PCIe 4.0 x4 mechanical slot for I/O scaling. Storage is optimized for SATA-centric builds via 6x SATA 6Gb/s ports, while an M.2 M-Key slot (2242/2280) offers a compact boot or cache device path over PCIe 3.0, supporting predictable serviceability in space-constrained chassis.

Why Choose the MC12-LE0 Gigabyte?

The MC12-LE0 Gigabyte prioritizes density-to-function efficiency by combining enterprise manageability, modern PCIe 4.0 I/O, and flexible DDR4 ECC capability in a compact microATX footprint. This design supports scalable rollouts for edge control-plane services, light virtualization, and departmental servers where remote lifecycle operations and straightforward component interoperability are critical.

Gigabyte engineering emphasizes platform stability, validated server management integration, and compatibility with modern data center operational practices, including UEFI firmware control and TPM-ready security foundations for standardized provisioning and compliance-aligned deployments.

Key Applications:

Edge compute and industrial control nodes
Light virtualization and control-plane services
SMB file, print, and infrastructure services
Dev/test and CI build agents
SATA-based storage-light servers

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your MC12-LE0 Gigabyte deployment, ensuring the right platform fit for your chassis, CPU, and I/O roadmap. For larger rollouts, Bulk Order Discount programs support predictable procurement for standardized edge and SMB server builds.

Technical details of MC12-LE0 Gigabyte

CPU Socket:

AM4

Onboard Memory:

RAID Support:

Yes

CPU Manufacturer:

AMD

CPU Supported Type:

Ryzen

Form Factor:

microATX

Chipset:

AMD B550

RAM Maximum Capacity:

128GB

Max RAM Frequency :

3200MHz

RAM Slots:

4 DIMM DDR4

RAM Channels:

Dual-Channel

PCIe Slots:

1 PCIe 4.0 x4 1 PCIe 4.0 x16

M.2 Slots:

1 PCIe 3.0 x1 M.2 2242, M.2 2280 M-Key

Network Ports:

2 RJ45 1 Gbps

ECC Support:

ECC Non-ECC

Onboard Network:

Ethernet

Suitability:

Workstation

Onboard CPU:

RAID Support:

Yes

Onboard Graphic:

Yes

Video Output:

1x VGA

USB Ports:

2x USB 3.2 Gen 1 Type-A 1x USB 3.2 Gen 1x2 1x USB 3.2 Gen 1 Type-A 1x USB 2.0

Other Ports:

1x Serial Port 1x MLAN port

Trusted Platform Module (TPM):

Yes

BIOS:

AMI UEFI

Wi-Fi Support:

None

Onboard Audio Chipset:

Embedded:

Yes

GPIO Pins:

Card Reader:

How long is the Warranty and how you can get technical support for MC12-LE0 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
