H223-V10-AAW1 Gigabyte Single Grace (Arm) 2U 6NH223V10MR000AAW1 Server Barebone

Product line:

Gigabyte H Series

See all Rackmount Servers 2U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SE4B7447-504159

Manufacturer Number:

6NH223V10MR000AAW1

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NH223V10MR000AAW1?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

H223-V10-AAW1 Gigabyte

High-Density 2U 2-Node AI and HPC GPU Server Barebone featuring NVIDIA GH200 with the H223-V10-AAW1 Gigabyte

The H223-V10-AAW1 Gigabyte is a rear-access 2U, 2-node platform engineered around the NVIDIA GH200 Grace Hopper Superchip per node, tightly coupling the Grace Arm CPU and Hopper GPU through NVLink-C2C to reduce latency and accelerate CPU-to-GPU data movement. This architecture targets large-scale AI training, high-throughput inference, and HPC workloads where memory bandwidth and fast interconnects are decisive for time-to-solution.

Per node, the H223-V10-AAW1 Gigabyte balances capacity and bandwidth using up to 480GB LPDDR5X ECC on Grace alongside up to 96GB HBM3 on the GPU, enabling efficient handling of large models and memory-bound simulations. PCIe Gen5 is leveraged end-to-end for I/O scalability: 8 hot-swap 2.5" U.2 NVMe bays and 4 M.2 NVMe slots support high-IOPS local datasets and checkpointing, while multiple Gen5 expansion paths enable high-speed NIC/DPU integration for scale-out fabrics and storage networking.

Why Choose the H223-V10-AAW1 Gigabyte?

The H223-V10-AAW1 Gigabyte delivers a density-to-performance profile suited for clustered deployments, providing 2 compute nodes per 2U with per-node Gen5 expansion and flexible networking options. It is designed for enterprise reliability with redundant power and remote management, and it scales predictably as a building block for AI pods and HPC clusters that require consistent node-level architecture and serviceability.

Gigabyte applies a data center engineering approach that emphasizes validated platform design, robust thermals, and standards-aligned manageability. The implementation integrates BMC and chassis management to support operational control, lifecycle processes, and integration into modern monitoring and automation workflows.

Key Applications:

Large-scale AI model training and fine-tuning
Low-latency AI inference services
HPC simulation and memory-bandwidth-bound analytics
Scale-out cluster compute with high-speed NIC/DPU fabrics

At Happyware - Server Hardware you benefit from non-binding offers tailored precisely to your GH200-based deployment plan and an extended warranty of up to 6 years to secure long-term operation for the H223-V10-AAW1 Gigabyte in production environments.

Technical details of H223-V10-AAW1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

Grace S1

CPU Family:

Grace

Supported CPU Manufacturer:

NVIDIA

Supported CPU Type:

Grace (Arm)

Supported CPU Generation:

5th

Supported CPU Codename:

Pascal

Nodes:

RAM Max. Total:

480GB

RAM Slots Total:

ECC Support:

ECC

Bays:

8x 2.5" HotSwap NVMe

Hot-Swap:

Yes

RAID Support:

PCIe:

4x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

4x PCIe 5.0 x16 Full-Height Half-Length

Onboard Network LAN:

4x RJ45 10 Gbps Intel X550-AT2

Onboard Network LAN Speed:

10 Gbps

Front I/O Ports:

LED Indicators System status LED CMC status LED Power button with LED System Reset button CMC reset button UID button with LED

IPMI / BMC integrated:

Yes

Power Supply Wattage:

3000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

Applications:

AI/Deep Learning AI Inference Compute Intensive Applications Database High End Enterprise Server Hyperconverged Infrastructure (HCI) Virtualization GPU Server Machine Learning (ML) High-Performance Computing (HPC) Enterprise

Onboard CPU:

Onboard Graphic:

Aspeed AST2600

Graphics Manufacturer:

ASpeed

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) ASPEED AST2520 Chassis Management Controller (CMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

OS:

Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C

How long is the Warranty and how you can get technical support for H223-V10-AAW1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
