H174-A80-IAS1 Gigabyte Dual Xeon 6900 1U 6NH174A80DR000IAS1 Server Barebone

Product line:

Gigabyte H Series

See all Rackmount Servers 1U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Not available

Happyware Article Number:

SE3B8529-591637

Manufacturer Number:

6NH174A80DR000IAS1

Brand:

Gigabyte

Are you a reseller?

Do you need help or a free consultation regarding our Services?

Contact our experts - we will assist You in finding the right services for Your requirements.

Do you need help?
Your contact

+49 4105 770000

Contact form

Description Technical details Warranty & Technical Support Reviews Bulk Deals

H174-A80-IAS1 Gigabyte

High-Density 1U 2-Node Compute Barebone featuring Intel Xeon 6 dual-socket architecture with the H174-A80-IAS1 Gigabyte

The H174-A80-IAS1 Gigabyte 2-node 1U rack server barebone is designed for consolidation where per-rack unit compute density and operational control are primary requirements. Each node supports up to 2x Intel Xeon 6 processors (Granite Rapids, LGA7529), enabling high core counts and modern platform features for virtualization clusters, HCI deployments, and analytics-heavy services with predictable scaling.

Memory bandwidth and capacity are addressed through DDR5 ECC Registered RDIMM/MRDIMM support with 12 DIMM slots per node, allowing large in-memory footprints and high VM density while maintaining enterprise-grade error protection. For I/O, the H174-A80-IAS1 Gigabyte exposes PCIe 5.0 expansion (1x x16 low-profile per node) and a storage design centered on Gen5 NVMe 2.5in hot-swap bays (2 per node), with optional SATA/SAS-4 via controller/backplane for mixed-media pools. Integrated management uses an ASPEED AST2600 BMC with IPMI and HTML5 KVM, complemented by chassis-level management to simplify multi-node operations.

Why Choose the H174-A80-IAS1 Gigabyte?

The H174-A80-IAS1 Gigabyte targets environments that need 2 independent dual-socket domains in 1U without compromising serviceability, making it a strong density-to-performance platform for private cloud and scale-out compute. Redundant hot-swap 80 PLUS Titanium power and hot-swap storage bays support uptime-focused deployment patterns, while PCIe 5.0 and DDR5 provide a scalable foundation for refresh cycles and workload growth.

Gigabyte engineers its enterprise platforms around standardized datacentre integration, focusing on manageable thermals, validated server components, and remote lifecycle control. The H174-A80-IAS1 Gigabyte aligns with modern rack power distribution via high-efficiency redundant PSUs and provides consistent manageability through IPMI-based tooling.

Key Applications:

Enterprise virtualization and consolidation
HCI and private/hybrid cloud compute nodes
HPC cluster compute density
Data analytics and in-memory processing
Scale-out microservices platforms

At Happyware - Server Hardware you benefit from non-binding offers tailored to node counts, storage options, and deployment targets for the H174-A80-IAS1 Gigabyte, enabling accurate BOM planning for cluster rollouts. For long-lived infrastructure programs, an extended warranty of up to 6 years adds procurement security for enterprise operations.

Technical details of H174-A80-IAS1 Gigabyte

Type: Rack

Suitability: Server

CPU Socket: BR (LGA 7529)

CPU Family: Xeon

Supported CPU Manufacturer: Intel

Supported CPU Type: Xeon 6900

Supported CPU Generation: 6th

Supported CPU Codename: Granite Rapids

Nodes: 2

RAM Type: RDIMM, MRDIMM

RAM Max. Total: 6TB

RAM Slots Total: 24

ECC Support: ECC

Bays: 2x 2.5" HotSwap NVMe, SATA, SAS

Hot-Swap: Yes

RAID Support: Yes

PCIe: 2x PCIe 5.0 x16 (x16 mode)

Expansion Slots: 2x PCIe 5.0 x16 Low-Profile

Onboard Network LAN: 2x RJ45 1 Gbps I350-AM2

Onboard Network LAN Speed: 1 Gbps

IPMI / BMC integrated: Yes

Chipset: System-on-Chip (SoC)

Power Supply Wattage: 3200W

Redundant Power Supply: Yes

Number of Power Supplies: 2

80 Plus Certificate: 80 Plus Titanium

Quantity of Cooler: 0

Performance Class: High-End

TDP (Thermal Design Power): 500W

Applications: Application-Optimized Solutions, Big Data, Cloud Computing, Data Center Optimized, Database, High End Enterprise Server, Hyperconverged Storage, Hyperconverged Infrastructure (HCI), Mission Critical, Virtualization, High-Performance Computing (HPC), Enterprise

Onboard CPU: No

Onboard Graphic: Yes

Graphics Manufacturer: ASpeed

Certificates: 80 Plus Titanium

Chassis Intrusion: No

OS: Citrix Hypervisor (formerly XenServer), Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu, Windows Server

How long is the Warranty and how you can get technical support for H174-A80-IAS1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
