G593-ZD2-LAX1 Gigabyte
High-Density 5U Liquid-Cooled GPU Server for HGX H100 (SXM5) Fabric with the G593-ZD2-LAX1 Gigabyte Platform
The G593-ZD2-LAX1 Gigabyte 5U liquid-cooled rack platform is engineered for NVIDIA HGX H100 with 8x SXM5 GPUs on an integrated NVLink/NVSwitch fabric, targeting sustained throughput for LLM training, GPU-accelerated HPC, and high-batch inference. Dual AMD EPYC 9005/9004 (SP5) processors provide high core density and strong PCIe Gen5 I/O to keep the HGX complex fed under continuous load.
Memory is built around 24x DDR5 RDIMM ECC slots across 12 channels per CPU, enabling large in-memory datasets and stable multi-tenant scheduling. Front hot-swap storage supports up to 8x 2.5in NVMe Gen5 drives for fast checkpointing and scratch workloads, with optional SATA/SAS-4 via an add-in controller. For OS and provisioning, 2x internal M.2 NVMe (PCIe Gen3, CPU-attached) allow separation of boot media from data paths. Expansion is PCIe Gen5-centric with 8x x16 low-profile slots and 4x x16 FHHL slots for high-speed NICs, DPUs, or storage accelerators.
Why Choose the G593-ZD2-LAX1 Gigabyte?
The G593-ZD2-LAX1 Gigabyte design prioritizes density-to-performance by combining liquid-cooled thermals with HGX H100 fabric bandwidth, enabling consistent clocks and predictable scaling across distributed training nodes. Integrated remote management, redundant power architecture, and serviceable hot-swap front NVMe bays support enterprise deployment models where uptime and fast maintenance windows are mandatory.
Gigabyte applies a pragmatic engineering approach focused on data centre operability: standards-based IPMI management, ECC-centric memory validation, and platform layouts aligned with modern rack integration, cabling discipline, and fleet lifecycle control.
Key Applications:
- LLM and multimodal model training
- GPU-accelerated HPC simulation
- High-throughput AI inference
- NVLink-enabled distributed compute
At Happyware - Server Hardware you benefit from non-binding offers tailored to your cluster and networking requirements for the G593-ZD2-LAX1 Gigabyte configuration, plus an extended warranty of up to 6 years to secure long-term operation in production data centres.
Technical details of G593-ZD2-LAX1 Gigabyte
How long is the Warranty and how you can get technical support for G593-ZD2-LAX1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
