G593-ZD1-AAX3 Gigabyte Dual EPYC 9004 5U 6NG593ZD1DR000ACX3 Server Barebone
Do you have a major deal consisting of various components? Then you're at the right place!
We offer you the best prices for your purchase:
- - If you already have an account with us, please log in. If you don't have an account, you can apply for one here.
- - simply collect your required items in the desired quantity in CART, and click the 'GET QUOTATION' button. and you're done!
- - You will receive your offer within the next 24 hours on working days.
Rev-3.x
Product line:Gigabyte G Series
Do you have questions about this product 6NG593ZD1DR000ACX3?
G593-ZD1-AAX3 Gigabyte
High-Density 5U GPU Server for HGX H200 AI Training featuring the G593-ZD1-AAX3 Gigabyte platform
The G593-ZD1-AAX3 Gigabyte 5U rack GPU server is engineered around NVIDIA HGX H200 with 8x SXM GPUs and an NVLink/NVSwitch fabric to sustain multi-GPU collectives and scale-out training. Dual AMD EPYC 9005/9004 (SP5) processors provide a balanced host layer for data pipelines, orchestration, and CPU-side preprocessing, with high TDP headroom for dense accelerator configurations.
Memory is provisioned through 24x DDR5 RDIMM ECC slots using a 12-channel-per-CPU topology, enabling high bandwidth for model shards, embedding tables, and large batch staging with capacity scaling up to 6TB. PCIe Gen5 expansion supports both FHHL x16 and low-profile x16 mechanical slots to integrate high-speed fabrics, storage controllers, and cluster interconnects without constraining GPU-centric airflow. For data ingestion, the storage plane offers 8x 2.5in hot-swap bays with NVMe Gen5 support, while optional controllers extend SATA/SAS-4 flexibility; dual internal M.2 NVMe slots provide isolated boot media.
Why Choose the G593-ZD1-AAX3 Gigabyte?
The G593-ZD1-AAX3 Gigabyte design targets maximum accelerator utilization per rack unit while preserving enterprise serviceability through hot-swap power and drive elements. It is optimized for predictable scaling in multi-node GPU clusters, combining high memory bandwidth, PCIe Gen5 I/O, and integrated management to streamline deployment, monitoring, and lifecycle operations across homogeneous AI and HPC fleets.
Gigabyte applies a platform engineering approach focused on datacenter fit: validated thermals for dense GPU operation, redundant power architecture, and standards-aligned remote management via an ASPEED AST2600 BMC with IPMI and HTML5 KVM. The G593-ZD1-AAX3 Gigabyte server is built to integrate cleanly into modern rack infrastructure with secure provisioning options such as TPM 2.0 support.
Key Applications:
- Large-scale AI model training and pretraining
- High-throughput NVLink GPU inference
- GPU-accelerated HPC simulation and analytics
- Enterprise AI virtualization and mixed workloads
- Multi-node GPU cluster deployments
At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration and rollout timelines for the G593-ZD1-AAX3 Gigabyte, helping you align procurement with cluster standardization. You can also extend the warranty up to 6 years to protect long-lived AI infrastructure investments.
Technical details of G593-ZD1-AAX3 Gigabyte
How long is the Warranty and how you can get technical support for G593-ZD1-AAX3 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
