G493-SB0-AAP1 Gigabyte

High-Density 4U GPU Server Barebone for PCIe Gen5 Accelerator Scaling with G493-SB0-AAP1 Gigabyte

G493-SB0-AAP1 Gigabyte is a 4U rackmount GPU server barebone engineered for multi-accelerator AI and HPC deployments, combining a dual-socket Intel Xeon Scalable 5th/4th Gen (LGA4677) platform with a C741 chipset to sustain high core-count CPU headroom alongside GPU throughput. The 32-slot DDR5 ECC RDIMM memory architecture delivers 16-channel aggregate bandwidth and capacity scaling up to 8TB, supporting data-hungry training pipelines, large model fine-tuning, and simulation workflows that benefit from high host memory density.

Designed around PCIe Gen5 expansion, G493-SB0-AAP1 Gigabyte exposes 8 full-height, full-length PCIe 5.0 x16 GPU slots to maximize accelerator density and predictable topology. Storage is optimized for mixed performance tiers via 12 hot-swap bays: 8 bays selectable as NVMe (PCIe Gen5 x4) or SATA, plus 4 additional SATA bays, enabling separation of high-IOPS datasets from capacity or staging volumes. A dedicated M.2 NVMe boot device preserves front-bay resources, while integrated 2x 10GbE and an AST2600 BMC with IPMI/HTML5 KVM streamline provisioning and remote operations.

Why Choose the G493-SB0-AAP1 Gigabyte?

G493-SB0-AAP1 Gigabyte delivers an enterprise-ready density-to-performance profile by pairing 8x PCIe Gen5 x16 GPU lanes with dual-socket compute and large DDR5 capacity, reducing node counts for clustered AI training, inference pools, or visual compute farms. The architecture supports scalable deployments with consistent serviceability through hot-swap storage and redundant power, while maintaining predictable resource allocation for validated, uniform GPU configurations.

Gigabyte focuses on platform engineering that aligns with modern data centre requirements for remote management, power resilience, and component interoperability, enabling standardized rollouts and controlled lifecycle operations in enterprise racks.

Key Applications:

AI training and LLM fine-tuning
AI inference and batch serving
HPC simulation and modeling
Visual computing and rendering
GPU-accelerated analytics

At Happyware - Server Hardware you benefit from non-binding offers tailored to your G493-SB0-AAP1 Gigabyte configuration and delivery requirements, enabling fast alignment with project timelines and procurement processes.

Technical details of G493-SB0-AAP1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

E (LGA 4677)

CPU Family:

Xeon

Supported CPU Manufacturer:

Intel

Supported CPU Type:

Xeon Scalable 5th Gen Xeon Scalable 4th Gen Xeon CPU Max

Supported CPU Generation:

4th 5th

Supported CPU Codename:

Emerald Rapids Sapphire Rapids

Nodes:

RAM Type:

RDIMM

RAM Max. Total:

8TB

RAM Slots Total:

ECC Support:

ECC

Bays:

8x 2.5"/3.5" HotSwap NVMe, SATA 4x 2.5"/3.5" HotSwap SATA

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

8x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

8x PCIe 5.0 x16 Full-Height Full-Length (Standard)

Onboard Network LAN:

2x RJ45 10 Gbps Intel X710-AT2

Onboard Network LAN Speed:

10 Gbps

Front I/O Ports:

VGA NMI button System status LED Storage Activity LED Power button with LED System Reset button USB UID button with LED

IPMI / BMC integrated:

Yes

Chipset:

Intel C741

Power Supply Wattage:

3000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Quantity of Cooler:

Performance Class:

Enterprise-Class

TDP (Thermal Design Power):

350W

Applications:

AI/Deep Learning AI Inference Visual Computing 3D Rendering Machine Learning (ML)

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Supported GPU Type:

PCIe

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

NVIDIA-Certified Systems™ - Data Center Servers NVIDIA-Certified Systems™ - OVX Servers

Chassis Intrusion:

OS:

Citrix Hypervisor (formerly XenServer) Red Hat Enterprise Linux SUSE Linux Enterprise Server Ubuntu VMware ESXi Windows Server

Operating Temperature:

10°C to 35°C

Non Operating Temperature:

-40°C to 60°C

Operating Relative Humidity:

8°C to 80°C

Non-operating Relative Humidity:

20°C to 95°C
