G294-Z22-AAP2 Gigabyte
High-Density 2U GPU Server Barebone for PCIe Gen5 Acceleration with the G294-Z22-AAP2 Gigabyte
The G294-Z22-AAP2 Gigabyte is a 2U rack GPU server barebone engineered as a PCIe Gen5 host for AI training, inference, and HPC acceleration where slot bandwidth and power delivery define performance. Built around a single-socket AMD EPYC 9005/9004 (SP5) platform, it scales core density up to 192 cores to sustain GPU feeding, CPU-side preprocessing, and high-concurrency virtualization on a unified NUMA domain.
Memory is optimized for throughput and resiliency with 12-channel DDR5 RDIMM ECC across 12 DIMM slots, enabling large in-memory datasets and stable long-duration compute runs. The PCIe topology prioritizes direct, full-bandwidth attachment through 8 PCIe 5.0 x16 FHFL GPU-capable slots plus 2 additional PCIe 5.0 x16 low-profile slots for fabric, storage, or DPU expansion. Storage design supports mixed tiers: 8 front 2.5-inch hot-swap bays with NVMe/SATA/SAS-4 capability (SAS via HBA) and dual PCIe 5.0 x4 M.2 NVMe boot, keeping OS and scratch separate from data volumes.
Why Choose the G294-Z22-AAP2 Gigabyte?
The G294-Z22-AAP2 Gigabyte delivers a balanced density-to-performance profile by combining a high-core EPYC SP5 CPU, PCIe Gen5 GPU scale, and serviceable hot-swap storage in a 2U footprint. It is suited to clustered deployments that require deterministic expansion lanes, redundant power headroom, and standardized remote management for repeatable rollouts.
Gigabyte designs this platform with data-center operability in mind, pairing high-efficiency redundant power, ASPEED AST2600 BMC with IPMI and HTML5 KVM, and enterprise-aligned integration options such as add-in RAID and optional TPM 2.0 support for policy-driven security baselines.
Key Applications:
- AI training and inference GPU hosting
- HPC simulation and modeling
- Accelerated analytics and data processing
- GPU-enabled virtualization and VDI
- NVMe-backed software-defined storage nodes
At Happyware - Server Hardware you benefit from non-binding offers tailored to your G294-Z22-AAP2 Gigabyte configuration and an extended warranty of up to 6 years to secure long-term operational planning for GPU-dense infrastructure.
Technical details of G294-Z22-AAP2 Gigabyte
How long is the Warranty and how you can get technical support for G294-Z22-AAP2 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
