G294-S45-AAP2 Gigabyte
High-Density 2U GPU Server Barebone for PCIe Gen5 Acceleration with the G294-S45-AAP2 Gigabyte
The G294-S45-AAP2 Gigabyte 2U rack barebone is engineered for accelerator-centric deployments that require predictable CPU-to-GPU balance, high-bandwidth I/O, and serviceable storage in a compact footprint. Built on dual Intel Xeon 6 (Granite Rapids / Sierra Forest) platforms, it supports high core-count configurations for orchestration, data preparation, and MPI-style control paths while keeping GPU lanes and memory bandwidth available for compute-heavy pipelines.
Its DDR5 8-channel memory architecture with 16 DIMM slots supports ECC RDIMM/MRDIMM configurations up to 4TB, enabling large model states, in-memory analytics, and high-throughput preprocessing. PCIe Gen5 expansion is optimized for dense GPU nodes with 8 FHFL x16 GPU-capable slots plus 2 additional x16 low-profile slots for fabric, storage, or instrumentation. The 8 x 2.5in hot-swap bays provide a mixed backplane strategy: 4 bays supporting NVMe Gen5/SATA/SAS-4 and 4 bays for SATA/SAS-4, allowing flexible tiering between local NVMe scratch and capacity media depending on controller and cabling choices.
Why Choose the G294-S45-AAP2 Gigabyte?
The G294-S45-AAP2 Gigabyte targets enterprises building scale-out GPU clusters where node repeatability, lane allocation clarity, and serviceability drive operational efficiency. With PCIe Gen5 slot density and dual-socket Xeon 6 headroom, it supports multi-accelerator configurations without sacrificing control-plane performance, while redundant 80 PLUS Titanium power and hot-swap components align with continuous-deployment data centre practices.
Gigabyte designs the platform with a focus on validated server thermals, consistent BOM control, and remote operations readiness. ASPEED AST2600 BMC management with IPMI enables secure out-of-band access, and modular OCP NIC 3.0 connectivity supports evolving network fabrics in modern rack-scale architectures.
Key Applications:
- AI training and inference clusters
- HPC simulation and modeling
- GPU-accelerated visual computing
- Dense virtualized accelerator pools
- High-speed data preprocessing
At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration goals for the G294-S45-AAP2 Gigabyte and procurement process, and you can extend the warranty up to 6 years to protect long lifecycle GPU infrastructure investments.
Technical details of G294-S45-AAP2 Gigabyte
How long is the Warranty and how you can get technical support for G294-S45-AAP2 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
