G294-S42-AAP1 Gigabyte Dual Xeon 6500 2U 6NG294S42DR000AAP1 Server Barebone
Do you have a major deal consisting of various components? Then you're at the right place!
We offer you the best prices for your purchase:
- - If you already have an account with us, please log in. If you don't have an account, you can apply for one here.
- - simply collect your required items in the desired quantity in CART, and click the 'GET QUOTATION' button. and you're done!
- - You will receive your offer within the next 24 hours on working days.
Gigabyte G Series
Not available
Do you have questions about this product 6NG294S42DR000AAP1?
G294-S42-AAP1 Gigabyte
High-Density 2U GPU Server Barebone featuring PCIe Gen5 Accelerator Scaling with the G294-S42-AAP1 Gigabyte
The G294-S42-AAP1 Gigabyte is a 2U rack GPU server barebone engineered for PCIe Gen5 accelerator density, combining dual Intel Xeon 6 CPU capability with a switch-based PCIe topology designed to keep multi-GPU workloads fed with lanes and bandwidth. It targets AI training/inference, HPC simulation, and visual computing where predictable PCIe behavior and serviceability are as important as peak throughput.
Built around 2-socket Intel Xeon 6 (Granite Rapids / Sierra Forest, Xeon 6500/6700 series), the platform exposes 24 DDR5 DIMM slots with 8-channel memory per CPU and ECC RDIMM/MRDIMM support for high-capacity, high-bandwidth configurations up to 6TB. For expansion, the G294-S42-AAP1 Gigabyte provides 8 full-height, full-length x16 GPU-capable slots via Broadcom/PLX PEX89048 PCIe Gen5 switches, plus 2 additional low-profile x16 slots for high-speed I/O. Storage is optimized for mixed scratch and dataset tiers using 8 front hot-swap 2.5-inch bays supporting Gen5 NVMe or SATA; SAS-4 is enabled through an add-in SAS controller, and RAID is implemented via add-in options with VROC header support.
Why Choose the G294-S42-AAP1 Gigabyte?
The G294-S42-AAP1 Gigabyte delivers a strong density-to-performance profile by concentrating PCIe Gen5 GPU expansion in 2U while maintaining enterprise manageability and modularity. Its dual-socket Xeon 6 design and switch-assisted PCIe layout simplify scaling from I/O-heavy inference to bandwidth-sensitive HPC, with redundant power and remote management suited to production clusters.
Gigabyte applies data center-focused engineering with validated platform integration, predictable thermals, and service-friendly layout aligned to modern rack standards, enabling consistent operations across AI and HPC deployments.
Key Applications:
- AI training clusters
- AI inference at scale
- HPC simulation and modeling
- GPU-accelerated visual computing
- Multi-GPU virtualization
At Happyware - Server Hardware you benefit from non-binding offers tailored to your configuration goals for the G294-S42-AAP1 Gigabyte, plus extended warranty options up to 6 years to secure long-lifecycle data center rollouts.
Technical details of G294-S42-AAP1 Gigabyte
How long is the Warranty and how you can get technical support for G294-S42-AAP1 Gigabyte
| Warranty: | 36 months (part) |
|---|---|
| RMA Url: | https://www.gigabyte.com/Support/Consumer/Warranty |
| Description: | Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard. |
| Support Portal: | https://support.happyware.com |
|---|
