G293-Z40-AAP1 Gigabyte Dual EPYC 9004 2U 6NG293Z40DR000ACP1 Server Barebone

Product version:

Rev-3.x

Product line:

Gigabyte G Series

See all Rackmount Servers 2U

See other Gigabyte products

This product is currently not priced. Request a personalized quote now.

Out of stock

Happyware Article Number:

SH7B6756-942970

Manufacturer Number:

6NG293Z40DR000ACP1

Brand:

Gigabyte

Are you a reseller?

Do you have questions about this product 6NG293Z40DR000ACP1?

Our team of server experts will be happy to help you to ensure you purchase the right product.

Description Technical details Warranty & Technical Support Reviews Bulk Deals

G293-Z40-AAP1 Gigabyte

High-Performance 2U GPU Compute Server Platform with dense accelerator expansion using the G293-Z40-AAP1 Gigabyte

The G293-Z40-AAP1 Gigabyte 2U rack barebone (SKU: 6NG293Z40DR000ACP1) is engineered as a multi-GPU PCIe accelerator node for AI training/inference, HPC simulation, and GPU-accelerated analytics. It is built on a dual-socket AMD EPYC 9005/9004 (SP5) platform, enabling high core density and strong per-socket I/O to sustain parallel workloads where CPU scheduling and PCIe lane availability are critical.

With DDR5 ECC RDIMM across 24 DIMM slots and a 12-channel per-CPU memory architecture, the G293-Z40-AAP1 Gigabyte supports large in-memory datasets and high bandwidth feeding multiple accelerators. Expansion is optimized around 8 full-height, full-length PCIe Gen5 x16 slots designated for GPUs, with validation for up to 8 dual-slot Gen4 GPUs via a PCIe switch, plus 2 additional PCIe Gen5 x16 low-profile slots for non-GPU adapters. Storage is organized for mixed tiers using 8 hot-swap 2.5-inch bays, combining NVMe/SATA/SAS and SATA/SAS options to balance scratch, dataset, and boot requirements.

Why Choose the G293-Z40-AAP1 Gigabyte?

The G293-Z40-AAP1 Gigabyte is a pragmatic choice for enterprises standardizing on PCIe-based multi-GPU nodes with predictable thermals, redundant power, and serviceable front-access storage. Its density-to-performance profile is designed for scale-out clusters, while integrated BMC management and dual 10GbE provide consistent operational control and deployment repeatability.

Gigabyte designs this platform around data-center governance: ASPEED AST2600 BMC with IPMI/HTML5 KVM for remote lifecycle operations, NCSI-enabled networking for out-of-band visibility, and hot-swap redundant 80 PLUS Titanium power to support continuous workloads under controlled power budgets.

Key Applications:

AI model training and inference
HPC simulation and numerical computing
GPU-accelerated rendering and visualization
Parallel data processing and analytics

At Happyware - Server Hardware you benefit from 24/7 Customer Service to align the G293-Z40-AAP1 Gigabyte configuration with your GPU, storage, and power requirements, and you can secure a non-binding offer tailored to your deployment volume and rollout schedule.

Technical details of G293-Z40-AAP1 Gigabyte

Type:

Rack

Suitability:

Server

CPU Socket:

SP5

CPU Family:

EPYC

Supported CPU Manufacturer:

AMD

Supported CPU Type:

EPYC 9004 EPYC 9005

Supported CPU Generation:

4th 5th

Supported CPU Codename:

Genoa Turin

Nodes:

RAM Type:

RDIMM

RAM Max. Total:

6TB

RAM Slots Total:

Memory Slots:

ECC:

ECC

Bays:

4x 2.5" HotSwap NVMe, SATA, SAS 4x 2.5" HotSwap SATA, SAS

Hot-Swap:

Yes

RAID Support:

Yes

PCIe:

8x PCIe 5.0 x16 (x16 mode) 2x PCIe 5.0 x16 (x16 mode)

Expansion Slots:

8x PCIe 5.0 x16 Full-Height Full-Length (Standard) 2x PCIe 5.0 x16 Low-Profile

Onboard Network LAN:

2x RJ45 10 Gbps BCM57416

Onboard Network LAN Speed:

10 Gbps

Front I/O Ports:

LED Indicators

IPMI / BMC integrated:

Yes

Chipset:

System-on-Chip (SoC)

Power Supply Wattage:

3000W

Redundant Power Supply:

Yes

Number of Power Supplies:

80 Plus Certificate:

80 Plus Titanium

Power Supply Cooler:

Quantity of Cooler:

Performance Class:

High-End

TDP (Thermal Design Power):

240W

Applications:

AI / Deep Learning AI Inference Enterprise Applications Enterprise Server High End Enterprise Server ML training Visual Computing GPU Server Visualization/Simulation High-performance Computing (HPC)

Onboard CPU:

Onboard Graphic:

Yes

Graphics Manufacturer:

ASpeed

Pre-installed Components:

None

Pre-installed Software:

ASPEED AST2600 Baseboard Management Controller (BMC) GIGABYTE Management Console web interface

Certificates:

80 Plus Titanium

Chassis Intrusion:

How long is the Warranty and how you can get technical support for G293-Z40-AAP1 Gigabyte

Warranty:	36 months (part)
RMA Url:	https://www.gigabyte.com/Support/Consumer/Warranty
Description:	Items must be returned first. The manufacturer does not send replacement items in advance. Delivery times are not guaranteed, and on-site service is not offered as standard.
